Lamborghini Huracán suspension upgraded by the premium manufacturer KW suspension
The Lamborghini Huracán makes a bold statement. As the successor to the Gallardo, it is the first Lamborghini to be based on the MSS (Modular Sportscar System) platform. With a naturally aspirated V10 engine delivering between 580 and 640 hp, it can accelerate from 0 to 62 mph in up to 3.2 seconds and reach a top speed of up to 201 mph. Added to this are its kart-like agility and high mechanical grip. The Lamborghini Piattaforma Inerziale (LPI) uses more than nine sensors to continuously process all movement states. The result is enormous precision. For enhanced steering feedback and a balance between comfort and firmness, our Lamborghini Huracán (Tecnica included) chassis upgrade offers unparalleled driving excellence.
Our coilover suspension for the Lamborghini Huracán (Tecnica included)
The factory suspension
The Lamborghini Huracán comes standard with a very direct suspension design with high basic rigidity. The lightweight body and low curb weight of around 1.4 tons support the agile, almost kart-like handling and ensure high mechanical grip. In everyday use, however, it becomes apparent that the hard basic setup and reduced noise insulation limit comfort reserves. In the EVO, the adaptive system filters out short bumps with ease, but still reacts noticeably stiffly to poor road conditions. For many drivers, this might be acceptable, but for us it is a clear starting point for further refinement.
KW V5
The Lamborghini Huracán KW V5 coilover suspension was developed for drivers who want to determine how their super sports car feels. At the heart of our coilover suspension is our Solid Piston Technology. This enables extremely precise damper tuning with sensitive response and maximum performance under load. The Huracán lowering of 10 to 25 mm (front) and 15 to 35 mm (rear) also ensures a sharper look and optimized aerodynamics. Ideal for those who are not looking for radical change, but rather an even more precise connection between driver and road. The KW V5 is the further development of an already exceptional concept for the Lamborghini Huracán (including Tecnica).
Customized lowering
This coilover suspension offers maximum possible lowering, customized to your vehicle model. You can also change this at any time after installation.
Adjustable rebound (low speed)
You'll notice the difference with every click! Here, you can adjust the low-speed rebound with 16 clicks. This adjusts the ride characteristics, making them either harder or more comfortable.
Adjustable rebound (high speed)
You'll feel the difference with every click! Here you can adjust the rebound (high speed) with a total of 13 clicks. This makes the riding characteristics either harder or more comfortable.
Adjustable compression damping (low speed)
You can fine-tune the low-speed compression damping even after installation. The vehicle's handling and stability will benefit from 12 clicks.
Adjustable compression damping (Highspeed)
You can fine-tune the high-speed compression damping even after installation. Up to 15 clicks allow you to adjust vehicle handling and stability.
Additional technologies
Twin tube solid piston
Tested on the 7-PostCustomized lowering
Composite spring seat
Trapezoidal thread
Technical component reportIs the KW V5 compatible with the factory lift system?
Yes. The KW V5 is available for models with the original lift system. This function remains fully intact. This allows you to combine everyday practicality with maximum performance without compromising the functionality of your Lamborghini Huracán. Despite the lowered suspension, you can remain relaxed on any surface. Even steep underground garage ramps or speed bumps can still be mastered with confidence and control.
What happens to the electronic damping system?
Depending on the model variant, your Huracán has electronic damping as standard. We offer the V5 for both variants. For models with electronic damper control, the standard control system is professionally deactivated by our KW deactivation specialists. This prevents error messages from appearing. Performance is significantly increased thanks to the more precise mechanical tuning of the solid piston technology.
Does everyday comfort improve?
The response is both more sensitive and more controlled. Bumps and uneven surfaces are handled more precisely without affecting the vehicle's characteristics. Despite its sportier design, the vehicle feels more harmonious and engaging overall than with the standard setup. On demanding roads or during rapid load changes in particular, the body moves more smoothly, the steering response is clearer, and contact with the road surface is more apparent.
Is the KW V5 suitable for track use?
In theory, the KW V5 is ideal for use on the track, offering consistent performance even under high loads. However, it is one of our Street Performance coilover suspensions. While it is primarily designed for maximum precision and driving dynamics on the road, it can easily handle track days. For Lamborghini Huracán drivers who expect maximum precision both on the road and occasionally on the track, the KW V5 is the most consistent solution.
